Anti-UAV Jamming Module Introduction and Working Principle:
Anti-UAV jamming module is a special device that uses radio sig nal
jamming technology to interfere with the communication link,
navigation positioning or control system of the drone. Its working
principle is mainly based on the coverage and interference
characteristics of radio sig nals. By transmitting the same jamming
signal as the working frequency band of the drone, the drone cannot
receive or process instructions normally, thereby preventing it
from flying or forcing it to land.
Specifically, the technologies that may be used in this module
include frequency hopping communication, spread spectrum
communication, anti-interference antenna, encrypted communication,
and intelligent identification and interference suppression. The
combined use of these technologies effectively improves the
survivability and mission completion rate of drones in complex
electromagnetic environments. For example, by interfering with the
2.4G and 5.8G frequency bands of the drone, it can lose the image
transmission signal and return; if the 1.5G frequency band is
further interfered, the drone can lose the GPS sig nal and make an
emergency landing.
| 50W Interference Power Amplifier Technical Data Sheet | |||||||
| Radio Frequency Index | |||||||
| Test item | Technical parameters | Unit | Remark | ||||
| Frequency Range | 420-5850 | MHz | Customized Frequency | ||||
| Operating Voltage | 28 | V | 28-32V | ||||
| Maximum Power Output | 47±0.5 | dBm | 50W@≤3.5A | ||||
| Gain | 42±1 | dB | peak-to-peak value | ||||
| In-band fluctuation | ≤2 | dB | peak-to-peak value | ||||
| Spurious Emission | Operating In-band | ≤15dBm/1MHz | dBm | Center Frequency add CW Signal to Maximum Power Output Test | |||
| Operating Out-of-ba nd | 9KHz~1GHz | No noise wave above normal base | dBm | ||||
1G~12.75GHz | dBm | ||||||
| Output VSWR | ≤1.30 | No power up:Standard Grid Output -10dBm | |||||
| ≤1.30 | Power up:Dual Directional Coupler Test | ||||||
| high-low temperature test | Operating Temperature | Ambient | -10~+55 | ℃ | Cold Start | ||
| Gain Stability | ±1.5 @-40℃~+55℃ | dB | |||||
| Power Stability | ±1 @-40℃~+55℃ | dB | |||||
| Power Supply Requirement | ≥4A@+28Vdc; | Continuous Wave Output 50W | |||||
| Power Supply Port | Power Cable:Red positive Black negative | Red positive Black negative | |||||
| RF Output Connector | SMA | SMA External Screw Base | |||||
As shown in the figure below, we will place the modules neatly in the packaging box and fill it with foam to avoid bumps during transportation, so that the goods can be delivered to customers safely and quickly.
